48v 100ah With Smart Bms 51.2v Lifepo4 Battery

Product characteristics

1. Advanced LiFePO4 battery cells
2. More than 5000 cycles @25℃ 0.7C conditions
3. JNGE hybrid inverters BMS compatible
4. Wall Mounted Similar Powerwall
5. 2.8kWh 5.6kWh 7.68kWh 11.2kWh optional
6. 51.2V Nominal Voltage
7. Maximum 1C charge and discharge capability
8. LCD displayer, support MODBUS, RS485, CAN ect. communication
9. Support max. 16 parallels
10. OEM service

share to:

Inquiry now

product introduction
More Details

Product Details

Product Features:

1. High efficient PWM charging ways.
2. Communication function: Rs485 to USB, WIFI, GPRS APP.
3. Battery charging parameters is settable.
4. Protection for any combination of photovoltaic module and battery reverse , no damage to any device.
5. Adopt traditional LCD display and keyboard design,convenient To view the running parameters of the controller, if need DC output, need customized.

Model	Energy storage battery
Type	YN-LP48-100-J
Voltage	51.2V
Rated capacitance	102Ah
Size	450×400 x150mm
Cycle life	≥5000cycles
MODBUS	RS485 CAN
Series parallel mode	1651p
BMS	51.2V100A BMS
Maximum continuous discharge current	100A
Instantaneous discharge current	110A
Charging cutoff voltage	58.4V
Discharging cutoff voltage	40V
Discharge temperature range	-30°C~60°C
Charge temperature range	-10°C~55°C
Storage temperature	-10°C~30°C
